Curtain Hook Spacing Calculator

🪝 Curtain Hook Spacing Calculator

Calculate perfect hook placement for even curtain distribution across any rod

Quick Presets:
Unit & Mode
Unit System
Calculation Mode
Panel & Style Details
Measure the finished/heading width of one curtain panel
Including hooks at both panel edges
Total panels on the window (e.g., 2 for a pair)
ℹ️ Rod Pocket Style: Rod pocket curtains slide directly onto the rod without hooks. No hook spacing calculation is needed. Consider switching to a different style if hooks are required.
✅ Hook Spacing Results
Hooks Per Panel
Hook Spacing
Total Hooks (All Panels)
Edge
Edge Hook Position
Style Spacing Reference
3–4 in
Pencil Pleat
Recommended
Per Pleat
Pinch Pleat
Hook Placement
Per Ring
Eyelet / Grommet
Hook Placement
Per Tab
Tab Top
Hook Placement
📌 First & Last Hook Rule: Always position the first and last hooks at the very edges of the panel heading. All intermediate hooks are then distributed evenly between them for a professional, uniform look.
Hooks Per Panel by Width (Pencil Pleat, 4 in spacing)
Panel Width (in) Panel Width (cm) Hooks Per Panel Actual Spacing (in) Actual Spacing (cm)
18 in46 cm54.5 in11.4 cm
24 in61 cm74.0 in10.2 cm
30 in76 cm84.3 in10.9 cm
36 in91 cm104.0 in10.2 cm
42 in107 cm114.2 in10.7 cm
48 in122 cm134.0 in10.2 cm
54 in137 cm144.2 in10.7 cm
60 in152 cm164.0 in10.2 cm
72 in183 cm194.0 in10.2 cm
84 in213 cm224.0 in10.2 cm
96 in244 cm254.0 in10.2 cm

* Hooks per panel = floor(width / 4) + 1, then spacing adjusted evenly. First and last hooks always at panel edges.

Recommended Spacing by Curtain Style
Curtain Style Hook / Ring Placement Typical Spacing (in) Typical Spacing (cm) Notes
Pencil PleatInserted into pleat tape3–4 in7–10 cmMost common style; use 3 hooks/tape pocket
Pinch PleatOne hook per pleat groupVaries by pleat countVariesPleats sewn at fixed intervals
Eyelet / GrommetOne hook per eyelet ring4–6 in10–15 cmRing spacing set during manufacturing
Tab TopOne hook per fabric tab4–6 in10–15 cmTab spacing set during manufacturing
Rod PocketNo hooks requiredN/AN/ARod slides through fabric sleeve
✨ Eyelet & Tab Tip: For eyelet and tab top curtains, the spacing between hooks is fixed by the manufacturing of the panel. Count the rings or tabs before purchasing hooks to ensure you have the correct quantity.
Hook Count Guide by Panel Count
Hooks Per Panel 1 Panel Total 2 Panels Total 3 Panels Total 4 Panels Total
5 hooks5101520
7 hooks7142128
9 hooks9182736
12 hooks12243648
14 hooks14284256
16 hooks16324864
19 hooks19385776
22 hooks22446688
25 hooks255075100

Always buy a few extra hooks per pack — it's common to need replacements over time.

Getting the distance between curtain hooks can change how the curtain look and hang. Usually, you lay ring each 4 to 8 inches but the number of pleat, the fullness of the fabric and own preferences also matter. If you space the hooks in 4 to 6 inches you escape around 70% of common problems about sagging.

That genuinely helps.

How to Space Curtain Hooks

And for curtains with heading tape, the hooks should lay about every 4 to 6 pockets. Make sure that the hooks are equally distributed on the tape. The three pockets on the heading tape allow you to move the curtain between 1 and 3 inches.

Before you gather the curtain, bind the strings at the other end with a sliding knot. Lay the hooks in the upper, middle or bottom pocktes… But never in the string, and space them equally every fourth pocket.

When you draw the string of wave or rufflette style curtains, the upper part folds and create that special style. The general advice is attach such hooks with distance of around 10 cm between each.

Start by putting a hook at every end of the hem of the curtain. Later continue by placing hooks at every seam, ensuring that they are equally spaced. When you reach the end, add last hook like at the start.

If you leave bigger spaces between the hooks, you will create more dramatic pleat.

Pleating tape has channels that are spaced in 1 inch. Here the pleating hooks fit to draw the fabric together. Good method is use the back tabs as centre and go 4 to 5 spaces on every side, to create more evident pleat.

For pencil pleat curtains, lay the hooks each 6 to 7 spaces; that longer interval gives more squeezed face.

Curtains of designers commonly use rings that do not slip. Instead, the rings have little eyelet, through that you put the hook, so that the curtain hangs from the ring. To count how many rings are needed, divide the length of the curtain rod by 3 for normal panels, or by 4 for full panels.

The simplest way to space the hooks is spread the fabric flat and lay hook at every end first. Ideally, the curtains should be threefold broader than the window. First count how many hooks are needed and later distribute them equally.

Lay two hooks at the central edge give extra stability and strength. With a curtain calculator you can find the amount of material, the lining, the header tape and the space for extra brackets and hooks for anywindow.
