🪟 Curtain Pole Length Calculator

Find the perfect pole length for any window — includes overhang, bracket positions & ring counts

Quick Presets
📏 Window & Pole Details
✅ Your Curtain Pole Results
📐 Overhang & Mount Guide
6 in
Min Overhang
Each Side
12 in
Ideal Overhang
Each Side
4–6 in
Mount Above
Window Frame
2–4 in
Bracket
Clearance
📋 Pole Length by Window Width
Window Width Pole Length (12 in overhang) Pole Length (6 in overhang) Recommended Rings
24 in / 61 cm48 in / 122 cm36 in / 91 cm5–7
36 in / 91 cm60 in / 152 cm48 in / 122 cm7–9
48 in / 122 cm72 in / 183 cm60 in / 152 cm9–11
60 in / 152 cm84 in / 213 cm72 in / 183 cm11–13
72 in / 183 cm96 in / 244 cm84 in / 213 cm13–15
90 in / 229 cm114 in / 290 cm102 in / 259 cm17–21
120 in / 305 cm144 in / 366 cm132 in / 335 cm23–27
💍 Ring Count by Panel Width & Spacing
Panel Width 4 in / 10 cm Spacing 5 in / 13 cm Spacing 6 in / 15 cm Spacing
24 in / 61 cm7 rings6 rings5 rings
36 in / 91 cm10 rings8 rings7 rings
48 in / 122 cm13 rings10 rings9 rings
60 in / 152 cm16 rings13 rings11 rings
72 in / 183 cm19 rings15 rings13 rings
84 in / 213 cm22 rings18 rings15 rings
🔧 Centre Bracket Spacing Guide
Pole Length Brackets Needed Max Unsupported Span Notes
Up to 47 in / 120 cm2 (end only)47 in / 120 cmNo centre bracket needed
48–71 in / 122–180 cm2–336 in / 91 cm1 centre bracket recommended
72–95 in / 183–241 cm336 in / 91 cm1 centre bracket required
96–119 in / 244–302 cm436 in / 91 cm2 centre brackets required
120 in+ / 305 cm+4+36 in / 91 cm2+ centre brackets required
🏠 Common Window & Pole Sizes by Room
Room / Window Type Typical Window Width Recommended Pole Pole Type
Bathroom24–36 in / 61–91 cm48–60 in / 122–152 cmSingle
Bedroom (small)36–48 in / 91–122 cm60–72 in / 152–183 cmSingle
Bedroom (master)48–60 in / 122–152 cm72–84 in / 183–213 cmDouble
Living Room60–72 in / 152–183 cm84–96 in / 213–244 cmDouble
Patio / French Doors72–96 in / 183–244 cm96–120 in / 244–305 cmDouble
Bay Window (single section)48–60 in / 122–152 cm72–84 in / 183–213 cmSingle per section
💡 Measuring Tip: Always measure the window frame width at the top — not the glass. Add your chosen overhang (at least 6 in / 15 cm each side) to get your minimum pole length. A 12 in / 30 cm overhang lets curtains stack clear of the glass, maximising natural light when open.
💡 Ring Count Tip: For standard gather (2x fullness), estimate 1 ring per 4–5 inches of panel width. For eyelet curtains, the grommets are pre-set at roughly 6–7 in apart. Remember: the first and last ring sit 1–2 in from each end of the curtain panel, not the pole end — so the pole should extend beyond the panel by at least your finial length.

For the right Length of the Curtain Pole everything seems a bit hard, but it simply comes down to measuring the window and adding some extra centimetres on both sides. The main rule is to measure the window frame and then add at least 15 cm on every side. Like this the suggested Length for the pole matches the window frame plus 30 cm.

When you plan to use heavier or wider curtains, you should add even more space on both sides, because dense material needs more area.

How to Measure and Choose a Curtain Pole

For curtains that hang in the niche, take away about 1 to 2 inches from the frame of the window. Here the curtains can hang freely, without getting stuffed against the frame. That measurement points the minimum needed Legnth for the pole.

If you extend the Curtain Pole past the frame of the window, expand it at least six inches each way. The extra Length gives more light and allows the curtains to form nice folds. Placing the end brackets at 10 to 15 cm past the frame supports stops gaps when the curtains close.

So a bit more Length is needed for the bottom hem and the finials.

Finials also add to the whole Length. For instance, if the Curtain Pole measures 150 cm and each finial 10 cm, the total reaches 170 cm. Placing the pole at 8 to 12 cm above the frame of the window is the usual spot.

It hides the upper fold of the curtains away from the eyes.

Poles longer than 240 cm need support from a central bracket, except in the case of special poles. For poles between 19 mm and 25 mm, the biggest Length without middle support is 180 cm. When trim or a radiator sticks out from the wall, longer brackets could be needed, so that the curtains hang before it.

The width of the pole also plays a role. The right thickness depends on the wait of the curtains. Poles of three-quarter-inch width work for light curtains or simple style.

One-inch poles are stronger and great for medium weight curtains. The available width ranges from 19 mm for lightweight fabric and goes up to 50 mm for heavy curtains of full Length with lining. Weighing the material of the curtain is the most reliable way to find what width the pole needs, instead of simply guessing based on kind of the fabric.

For window sizes, short poles of around 24 inches work for windows between 20 and 40 inches. Medium Length poles at 48 inches suit for windows of 40 to 84 inches. Curtains that hang as high and wide as possible is widely thebest choice.

At 6 to 8 inches from the ceiling it looks best.
